Actually, due to this feature, wet etching of crystalline silicon carbide is extremely difficult as SiC is totally inert to all aqueous etching solutions at room temperature [ 76 ]. To our knowledge, the lowest etching temperature referenced in the literature was mentioned by Chu and Campbell in [ 77 ]. The use of other solutions like KOH is also feasible but it requires higher temperatures [ 78 ].

In addition, wet etching is often isotropic and, due to the severe conditions required for silicon carbide etching, difficult to localize. Consequently, due to the huge difficulties of wet silicon carbide etching, many efforts were enforced to develop a more user-friendly method. This is the case for plasma etching, which has since been the subject of intense research for decades. Historically, reactive ion etching RIE using a capacitively coupled plasma CCP reactor was massively investigated during the ss.

In this configuration usually just called RIE , a RF electromagnetic field is applied between the two electrodes located on both sides of the reactor. Then electrons are accelerated by the high-frequency electric field and ionize the molecules of the gas, leading to a plasma. Consequently, the ions produced can react with the material to etch. For that matter, this behavior is the source of the RIE appellation. Typically, this chemical reaction is isotropic, leading to sloped sidewall profiles. In contrast, according to ion energy, a sputtering effect of the material can also be observed, which mainly results in an anisotropic etching, then to vertical sidewalls.

The two effects coexist and the predominance of one effect compared with the other depends on the etching parameters power, pressure, etc. Therefore, in the s, another configuration was developed with the emergence of inductively coupled plasma ICP reactors.

MillennTechnologies Introduction Nickel Silicon Carbide Coatings

In such a reactor, the plasma, generated by a RF magnetic field as previously shown RIE power , is also contained inside the chamber, which is encircled by an inductive coil ICP power. The great advantage of this configuration, in comparison with a RIE reactor, is the possibility to independently control the ion energy with the RIE power and their densities with the ICP power. Silicon carbide plasma etching has been largely investigated. However, as previously mentioned, silicon carbide is a material that is difficult to etch.

This is also the case using plasma etching. Then, the success of SiC plasma etching involves the use of severe conditions, which are rarely compatible with the masking materials. For example, photoresist, which is a classical masking material for plasma etching, only operates for thin SiC layers according to the etching selectivity, classically around 1. Silicon dioxide films have also been investigated to act as a mask for plasma etching but it requires thick layers, typically several microns [ 80 , 81 ]. As a consequence, due to the poor selectivity of these materials, a metallic mask is usually preferred.

Among them, aluminum has been largely investigated and results to a selectivity at least one order of magnitude higher than the one observed with photoresist [ 82 , 83 ].
